Power Requirements: 240v 60Hz 3-phase 30 amp max
Safely and efficiently clean your tooling with the user-friendly and cost-effective Natoli 3-Piece Ultrasonic Cleaning System. The convenient side-by-side design makes transferring punches and dies quick and easy, reducing the risk of tool damage during handling. Units are CE approved.
- Allen Bradley PLC digitally controls time, temperature, and power
- Rounded tank with center drain to prevent “pooling” of water
- Built-in alarms for maximum safety
- 304 stainless steel lift-off lids reduce contamination points
- All units meet FCC regulations and are CE compliant
Optional Features
- Automatic fill and/or drain tanks
- Water recirculation and filtration
- Auto-detergent injection
- Spray rinse before and after tools enter/leave rinse tank
- High-temp drying—up to 225˚F
- Air knife blasts tools entering and leaving the drying unit
- Rigibot transfer arm
Dimensions
- Overall dimensions of wash and rinse units: 32x54x43in (812.8×1371.6×1092.2mm)
- Tank dimensions of wash and rinse units: 18x26x18in (16in Water Fill Depth) (457x660x457mm; 406.4mm WFD)
- Overall dimensions of dry unit: 47x54x43in (1193.8×1371.6×1092.2mm)
- Tank dimensions of dry unit: 22x30x20.75in (558.8x762x527.05mm)
